Technical Specs
Power
Power 2.8 kW
Power source Electric
Motor class Induction
Frequency 50 Hz
Working system
Total stop system (TSS) Yes
Max pressure 150 Bar
Working pressure 140 Bar
Max rated flow 550 l/h
Working rated flow 500 l/h
Max water inlet temperature 50 °C
Pump mechanical system Wobble plate
Pump material Brass
Pistons number 3
Piston material Stainless steel
Self priming Yes
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A) 97
Measured sound power level dB(A) 95
Measured sound pressure level at operator ear dB(A) 83.4
Vibration level hand (m/s2) < 2.5
Overall dimensions
Pack weight 29.7 kg
Weight 27.7 kg
Product length 428 mm
Product width
420 mm
Product height 903 mm
