Technical Specs
Power
Power 3.3 kW
Power source Petrol
Engine Brand Honda
Engine model GCVx170 OHV Autochoke
Displacement 167 cm³
Engine rotation speed 2900 rpm
RPM control Fixed rpm
Starter Recoil
Fuel tank capacity 0.95 L
Engine Oil tank capacity 0.4 L
Suggested working area 1000 ㎡
Cutting system
Cutting width 53 cm
Deck material Galvanized steel
Cutting height adjustment Centralized
Cutting height positions 7 positions
Cutting height range 25 - 77 mm
Drive system
Driving Self-propelled with speed variator
Traction Rear-wheel drive
Speed forward 2.7 to 4.4 Km/h
Equipment
Collector capacity 70 L
Handlebar type Ergonomic 25 mm adj. by button + soft grip
Wheels 210/240mm grooved wheels on ball bearings
Vibe Control System (VCS) Yes
Front handle Yes
Adjustable handlebar Yes
Foldable handlebar Yes
Washing link Yes
Collector type Textile (plug-in) with warn
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A) 98
Measured sound power level dB(A) 98
Measured sound pressure level at operator ear dB(A) 86
Vibration level hand (m/s2) 8
Overall dimensions
Pack weight 51.2 kg
Product length 1680 mm
Product width 560 mm
Product height 1150 mm
Weight 45 kg
