Handle-transmission

Handle-transmission assembly details for Mountfield MB28 2008 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0018562620/1Handle Ass.Y (Incl.2-12)£28.73 Add to
0022123030TORX SELF-THREAD SCREW£1.79 Add to
0032123100SCREW M4 8 x 13£1.79 Add to
0043743475SAFETY LEVER£3.15 Add to
0053654300SPRING£1.79 Add to
0063743465THROTTLE LEVER£4.82 Add to
0073654270/1Spring£4.60 Add to
0083612710Stop Plate£5.66 Add to
0092123070TORX SELF-THREAD SCREW£1.79 Add to
0103749270STOP KNOB£1.79 Add to
0113749910Reduction£4.01 Add to
0124252540Wire Ass.Y£7.81 Add to
0133786030WIRES GUARD SHEATH BC 4T MONO£12.22 Add to
0143211570Coil-Switch Cable£7.58 Add to
0153211120CABLE£5.87 Add to
0168563590POIGNEE LANCEUR ANT. STAR 22-3£50.95 Add to
0172135050TORX SCREW M5 x 30£1.79 Add to
0182312090FLAT WASHER D=5 x 10 x 1£1.79 Add to
0192412030NUT M5 x 5 x 8£1.79 Add to
0208251211TRANSMISSION PIPE ASSEMBLY£101.13 Add to
0214251410TRANSMISSION SHAFT ASSEMBLY£46.61 Add to
0223642221Bearing Hub (OBSOLETE)N/A
0234121881/1Clutch Drum£20.50 Add to
0248561600SUPPORT TRANSMISSION ASSY VIP£34.35 Add to
0253353080CIRCLIP D=32mm£1.79 Add to
0263112170Bearing (OBSOLETE)N/A
0272123140Screw£4.01 Add to
0282123150Screw£4.01 Add to
0292135160SCREW TX M6 x 19£1.79 Add to
0322312150WASHER 5.5 x 15 x 1.5£1.79 Add to
0332135060TORX SCREW M5 x 25£2.00 Add to
0342135030TORX SCREW M5 x 20£1.79 Add to
0353615000LINE CUTTER£8.32 Add to
036112154330/0LOW SELF-LOCKING NUT M5£2.06 Add to
0383L8563570/1SAFETY COVER ASSEMBLY£21.83 Add to
0394253460SINGLE HARNESS£17.27 Add to
