Handle-transmission

Handle-transmission assembly details for Mountfield MB28D 2008 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0018563830THROTTLE HANDLE ASSEMBLY (OBSOLETE) (OBSOLETE)N/A
0022123030TORX SELF-THREAD SCREW£1.79 Add to
0032135050TORX SCREW M5 x 30£1.79 Add to
004112154330/0LOW SELF-LOCKING NUT M5£2.06 Add to
005118800202/0EXTINCTION SWITCH£2.18 Add to
006323315083/0THROTTLE LEVER [RED]£2.00 Add to
0073743441SAFETY LEVER£1.79 Add to
0083654270/1Spring£4.60 Add to
0093654280/1Spring£4.60 Add to
0104252720CABLE ACCEL. STAR 26D/31D 96CM£8.32 Add to
0113786240Wire Sheath (OBSOLETE)N/A
0123211650Coil-Switch Cable£7.19 Add to
0133211660Earth Cable£7.19 Add to
0144252710/1Handle Ass.Y£103.90 Add to
0153744860/1Left Knob£14.67 Add to
0168250397SUPPORT ASSEMBLY STAR 26D/£65.70 Add to
0172135120SCREW TX M5 x 40£1.79 Add to
0182312090FLAT WASHER D=5 x 10 x 1£1.79 Add to
0203721410RUBBER SLEEVE£1.79 Add to
0212123110SCREW 4.8 x 35£1.79 Add to
0223657470HANDLE LOCK DUPLEX£1.79 Add to
0233744162SILENTBLOC MANCHE STAR£19.48 Add to
0248251211TRANSMISSION PIPE ASSEMBLY£101.13 Add to
0254251410TRANSMISSION SHAFT ASSEMBLY£46.61 Add to
0263642221Bearing Hub (OBSOLETE)N/A
0274121881/1Clutch Drum£20.50 Add to
0288561600SUPPORT TRANSMISSION ASSY VIP£34.35 Add to
0293112170Bearing (OBSOLETE)N/A
0303353080CIRCLIP D=32mm£1.79 Add to
0312123140Screw£4.01 Add to
0322123150Screw£4.01 Add to
0332135160SCREW TX M6 x 19£1.79 Add to
0348562512HARNESS SUPPORT ASS.Y£36.38 Add to
0363642530Pin£4.01 Add to
0382312150WASHER 5.5 x 15 x 1.5£1.79 Add to
0392135060TORX SCREW M5 x 25£2.00 Add to
0402135030TORX SCREW M5 x 20£1.79 Add to
0413615000LINE CUTTER£8.32 Add to
0422432040NUT M5£1.79 Add to
0443L8563570/1SAFETY COVER ASSEMBLY£21.83 Add to
0454253460SINGLE HARNESS£17.27 Add to
