Gear case

Gear case assembly details for Mountfield MB3502 2008 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0014252780/1Gear Case Assy (OBSOLETE) (OBSOLETE)N/A
0072135050TORX SCREW M5 x 30£1.79 Add to
0082653090SCREW M5X11,5£1.79 Add to
0092653460SCREW£4.52 Add to
0153121170RING 22X32X7£4.52 Add to
0161L3641700/1SPACER£9.28 Add to
0173641640UPPER RING NUT£10.36 Add to
0183612640LOWER RING NUT£7.51 Add to
0194560610STABILIZER BOWL 127mm X 8M (OBSOLETE) (OBSOLETE)N/A
0202321230WASHER 8.2 x 18 x 1£1.79 Add to
0212653170BOLT M8 X 28£5.19 Add to
0224611880BLADE 4 TEETH 255mm£12.40 Add to
0313L4353240/1NYLON HEAD [M8-MALE LH-THREAD]£23.87 Add to
