Cutting unit

Cutting unit assembly details for Mountfield MH2230K 2008 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	6990122	CLUTCH DRUM ASS.Y	£36.77	Add to
002	6990199	Upper Case	£89.48	Add to
003	6990153	Grease Dispenser	£5.21	Add to
004	6990205	Screw	£4.01	Add to
005	6990141	SCREW	£1.79	Add to
006	6990200	LOWER CASE	£32.99	Add to
007	6990202	Gasket	£8.23	Add to
008	6990151	NEEDLE BEARING	£7.51	Add to
009	6990183	Shoe	£7.81	Add to
010	6990139	Screw	£4.01	Add to
011	6990157	CONNECTING ROD	£46.61	Add to
012	6990150	Elastic Ring	£4.01	Add to
013	6990186	SPROCKET	£170.61	Add to
014	6990193	PINION (M12XP1.5)	£61.09	Add to
016	6990152	NEEDLE BEARING	£26.46	Add to
021	6990182	BOTTOM BLADE	£72.50	Add to
022	6990181	TOP BLADE	£72.50	Add to
023	6990192	BLADE HOLDER	£71.96	Add to
024	6990198	BLADE GUARD	£18.29	Add to
025	6990180	Blades Holder Plate	£9.32	Add to
026	6990196	SCREW	£2.87	Add to
027	6990184	DEFLECTOR	£18.41	Add to
028	6990146	NUT	£1.79	Add to
029	6990121	WASHER	£1.79	Add to
030	6990197	SCREW L=29	£3.09	Add to
031	6990194	HANDLE, RIGHT	£34.60	Add to
032	6990179	KNOB	£15.91	Add to
033	6990210	Washer	£4.01	Add to
035	6990207	Screw	£4.01	Add to
036	6990204	Screw (OBSOLETE) (OBSOLETE)	N/A
037	6990128	RETAINER	£5.87	Add to
038	6990201	Plate	£10.31	Add to
040	6990209	Nut	£4.01	Add to
041	6990206	Screw	£4.01	Add to
042	6990191	Cap	£6.05	Add to
043	6990189	GROMMET	£4.91	Add to
044	6990188	Spacer	£6.62	Add to
045	6990211	Screw	£4.01	Add to
046	6990190	Handle Fixing Plate	£6.94	Add to
047	6990203	LEFT HANDLE TUBE	£32.69	Add to
048	6990187	Handle Support	£12.62	Add to
049	6990208	Nut	£4.01	Add to
050	6990212	Hind Handle Assy	£106.90	Add to
051	6990195	BLADE COVER	£18.11	Add to
