Blade

Blade assembly details for Mountfield S501R-PD-294519043-M16 2016 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001381207230/0ENGINE MOUNTING PLATE AVS MP2 [YELLOW]£34.81 Add to
002322551536/0PLATE£4.10 Add to
003112728210/0SCREW TORX M4 x 10£1.79 Add to
004322250014/0AVS RUBBER DAMPER£5.60 Add to
005122519816/0PIN£10.91 Add to
006322672201/0RUBBER GROMMET£6.27 Add to
007122170850/0SPACER£3.55 Add to
008112521350/0WASHER M8 8.4 x 16 x 1.6£2.06 Add to
009112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
010122450439/0TENSION SPRING£3.69 Add to
011112727801/0SCREW TCB TORX M6 x 20£2.06 Add to
012122170846/0SPACER£3.55 Add to
013112154510/0LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S£2.06 Add to
015122465648/0BLADE BOSS D=22£16.23 Add to
016181004415/0TWINCLIP BLADE 50£58.87 Add to
017322672110/1FRICTION WASHER 18.3 x 60 x 1.5£1.91 Add to
018322672105/0BLADE WASHER 60 x 18 x 2£1.91 Add to
019112508120/0SPRING WASHER 18.4 x 50 x 2£3.72 Add to
020122041943/0BUSH£10.02 Add to
021112736820/0HEX-HEAD SCREW 3/8" x 3"£2.71 Add to
