Roller

Roller assembly details for Mountfield S461R PD LS (299489543/M19) 2020 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	112735662/1	SCREW TCB TORX M6 x 12	£2.87	Add to
002	112523040/0	WASHER M6 6.6 x 18 x 1.6	£2.06	Add to
003	1111-3562-01	ROLLER CHAIN (RIVETED)	£20.45	Add to
003	1111-3562-01	ROLLER CHAIN (RIVETED)	£20.45	Add to
004	1111-3424-01	SPROCKET 21T	£18.28	Add to
004	1111-3424-01	SPROCKET 21T	£18.28	Add to
005	1111-3423-01	SPROCKET 10T	£15.13	Add to
005	1111-3423-01	SPROCKET 10T	£15.13	Add to
006	122170970/0	SPROCKET SPACER	£2.47	Add to
007	322672151/0	ANTI-FRICTION WASHER 12.2 x 30 x 0.8	£1.91	Add to
008	321660100/0	THRUST WASHER 13 X 22 X 0.5	£2.32	Add to
009	322038404/0	DRIVE AXLE BUSH	£2.06	Add to
010	322785126/0	BEARING SUPPORT	£12.00	Add to
011	119216035/0	BEARING 6001 2RS (12 x 28 x 8)	£3.83	Add to
012	112610095/0	CIRCLIP D=28	£2.06	Add to
013	122601909/0	PULLEY	£6.01	Add to
014	135063800/0	TRAPEZOIDAL BELT Z 27 LP=710(BRONZE GEAR)	£11.01	Add to
014	135063800/0	TRAPEZOIDAL BELT Z 27 LP=710(BRONZE GEAR)	£11.01	Add to
015	112645705/0	ROLL PIN D=5 x 32	£2.02	Add to
016	181003077/1	GEARBOX GT VE2002 EVO WBH STEEL ROLLER	£102.01	Add to
017	125430220/0	SPRING	£4.52	Add to
018	112000957/0	CIRCLIP D=10	£2.59	Add to
