85 COMBI TRANSMISSION

85 COMBI TRANSMISSION assembly details for Mountfield 2100 series 2009 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	387203000/0	SHORT BLADE SHAFT ASSEMBLY	£115.14	Add to
005	9945-0825-16	SCREW M6SF M8 x 25	£2.32	Add to
006	1134-9116-01	BLADE BAR ASSEMBLY 85C [2 PCS]	£95.67	Add to
007	1134-9119-01	BLADE TIP KIT [2 PCS]	£35.15	Add to
008	1134-9054-01	SHEAR BOLT KIT [6 x Bolts & Nuts]	£8.84	Add to
009	1134-6311-01	BOLT 7/16" UNF	£3.24	Add to
010	1134-6312-01	LOCK NUT 7/16" UNF	£2.87	Add to
011	1134-6211-01	BLADE WASHER	£3.55	Add to
012	9997-1060-12	SCREW M6S M10 x 60	£2.54	Add to
020	1134-6280-05	TRANSMISSION COVER [BLACK]	£42.83	Add to
021	1134-0240-01	SCREW	£9.82	Add to
022	112293201/0	HEXAGON NUT M8 WITH EXAGONAL FLANGE	£2.06	Add to
023	1134-6423-01	SUPPORT	£23.21	Add to
025	1134-5595-01	BLIND RIVET NUT	£8.32	Add to
027	1134-6429-01	BELT GUIDE	£15.54	Add to
029	1134-6287-01	TOOTHED BELT PULLEY	£25.21	Add to
030	1137-0010-01	PULLEY	£38.44	Add to
031	9600-0168-01	KEY	£4.52	Add to
033	1134-5406-01	WASHER M10 10.5 x 35 x 5	£4.23	Add to
034	1134-9182-01	TOOTHED BELT	£35.71	Add to
035	1134-5400-04	SPACER	£5.32	Add to
036	1134-9109-01	DECK DRIVE BELT	£46.61	Add to
