Iseki TM3185 Compact Tractor 16hp with F6/R2 Mechanical Transmission 4WD

Very lightweight, compact and highly manoeuvrable in tight areas, the TM Range of tractors are ideally suited to gardens, schools and small sports turf areas like tennis courts. With these attributes the TM can also be found maintaining artificial turf, where its light footprint is an advantage.

TM3187 Compact Tractor feature an ISEKI 3 cylinder, clean burn, liquid cooled, 928cc, 11.5kW (16hp) diesel engine with a 14 L fuel tank. Category one 3-point linkage lift capacity of 540kgs. Standard equipment includes; power steering; mechanical transmission 6F/2R; selectable 2WD & 4WD with differential lock; folding ROPS, rear PTO; front & rear hitch; road homologation including headlights, turn signals, mirror and reflectors; 7-pin trailer lighting socket. With Agri Tyres or Turf Tyres.

Free Local Delivery Within 30 Miles by our own Driver to your door fully built and ready to cut grass

Specifications

Power Engine: Type Diesel indirect injection, overhead valve

Displacement 761cc

No of cylinders 3

Power 11.8kW (16hp) at 2700rpm

Fuel capacity 14ltr (3.2gal)

Rated engine speed 2700rpm

Transmission Main Clutch Mech

Gear forward/reverse F6/R2

Speed 1.2km/h to 20.1km/h

Driven Wheels 4WD

Differential Lock Standard

Brakes Type Wet discs

Tyres Type Turf or Ag

Front 5.00-12 (Ag) 20x8-10 (Turf)

Rear 9.5-16 (Ag) 212/80D-15 (Turf)

PTO Engagement Mechanical Clutch

Rear PTO at engine rpm 540 @ 2500rpm

Hydraulics Steering Power Steering

Main System Engine mounted gear pump Max output Steering: 4.4 L/min Main system 13.5 L/min @2700rpm

Three point lift Category 0

Lift Capacity 540kg at ball ends, 280kg @ 24”

ROPS Type Rear foldable

Dimensions Length 2.46m

Width 1.105m across rear at ROPS mounted lamps

Height with ROPS 2.28m

Weight 575kg

Wheelbase 1.27m

ONLY £14486.40

Add to basket
