Power Engine: Type Diesel indirect injection, overhead valve
Displacement 1498cc
No of cylinders 3
Power 18.2kW (24.4hp) at 2500rpm
Fuel capacity 28ltr (7.4gal)
Rated engine speed 2500rpm
Transmission Main Clutch F8/R8
No of speeds 8
Forward 0.5-24.4kph (0-15.2mph)
Driven Wheels 4WD
Differential Lock Standard
Brakes Type Wet discs
Tyres Type Turf or Ag
Front 6-12 (Ag) 24x8.50-12 (Turf)
Rear 9.5-16 (Ag) 315/75D-15 (Turf)
Rear PTO 1 speed 540 @ 2475rpm
Mid PTO 1 speed 2000 @ 2461rpm
PTO Shaft 1 3/8” 6-spline
Hydraulic Lift capacity 600kg (1332lb) or 800kg (1764lb) with high capacity lift kit
Pump Capacity ltr/m 20.8
Position Control Standard
Rear linkage type Category 1
ROPS Type Rear foldable
Dimensions Length 2.88m (113.4”)
Width 1.1m (43.7”) (Ag tyres) 1.295m (51”) (Turf tyres)
Height 2.39m
Weight 870kg (1918lb)
Ground Clearance 0.25m (9.8”)
