Transmission

Transmission assembly details for Stiga SBC 645 KF 2018 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001118802512/0CLUTCH DRUM£18.44 Add to
002112610800/0CIRCLIP D=35£2.06 Add to
0033112150BEARING£20.51 Add to
004112609200/0CIRCLIP D=15£2.06 Add to
005118804827/0Output BlockN/A POA
006112521330/0WASHER M6 6.4 X 12 X 1.6£2.06 Add to
007112521330/0WASHER M6 6.4 X 12 X 1.6£2.06 Add to
008112728721/0SCREW M6 x 30£1.91 Add to
0102135010TORX SCREW M5 x 14 - NLA£1.79 Add to
011112521320/0WASHER M5 5.3 x 10 x 1£2.06 Add to
012112521320/0WASHER M5 5.3 x 10 x 1£2.06 Add to
013112760475/0SCREW TC M5 x 20£2.06 Add to
014118802595/0KNAPSACK CONNECTING PIPE£9.41 Add to
015112792099/0HEX HEAD SCREW M6 x 30£1.79 Add to
016118803486/0TRASMISSION PIPE ASSY£47.97 Add to
018118802593/0TRASMISSION SHAFT£13.91 Add to
019118802594/0CONNECTED SETS£4.52 Add to
020118804828/0ENGINE SUPPORT FLANGE£1.79 Add to
021118804829/0FIX PIN£5.46 Add to
022118804832/0FLEXIBLE PIPE AND SHAFT ASSEMBLY£42.59 Add to
052112728440/0SELF-TAPPING SCREW 4.8 X 13£1.79 Add to
053118802544/0LEFT HANDLE, GREY£16.91 Add to
054118802516/0KNAPSACK FLAMEOUT LINE£8.32 Add to
055118802514/0Conductor casingN/A POA
056118802515/0KNAPSACK THROTTLE CABLE£7.23 Add to
057118802551/0SHOCK REAR HANDLE TRIGGER TORSION SPRING£2.06 Add to
058118802548/0DAMPING PLATE£2.06 Add to
059118800202/0EXTINCTION SWITCH£2.18 Add to
060118802550/0DAMPING PLATE AFTER PLATE MACHINE HANDLE£3.41 Add to
061112760475/0SCREW TC M5 x 20£2.06 Add to
062118802551/0SHOCK REAR HANDLE TRIGGER TORSION SPRING£2.06 Add to
063118802549/0SHOCK REAR HANDLE PLATE MACHINE£2.06 Add to
064118802547/0SHOCK REAR HANDLE REAR SUPPORT D. 28£3.55 Add to
065112154330/0LOW SELF-LOCKING NUT M5£2.06 Add to
066118802543/0REAR HANDLE BUMPERS£3.41 Add to
067118802545/0IGHT HANDLE, GREY£16.91 Add to
068118802543/0REAR HANDLE BUMPERS£3.41 Add to
069118802546/0SHOCK REAR HANDLE FRONT SUPPORT D. 28£5.73 Add to
070118802535/0PROTECTIVE FRONT HANDLE BAR£3.69 Add to
071118802541/0DAMPING HANDLE LOCK SET£3.96 Add to
072118802540/0RUBBER SLEEVE£3.81 Add to
073112521330/0WASHER M6 6.4 X 12 X 1.6£2.06 Add to
074118802542/0LOCKING SCREW£3.64 Add to
075118802534/0FRONT D HANDLE [GREY]£26.18 Add to
076112291000/0HEXAGON NUT M5£2.06 Add to
077118802513/0STRAP PENDANT WHITE£3.17 Add to
