CONTROLS

CONTROLS assembly details for Stiga PARK COMBI 100 Q PLUS (2D6210028/ST2) 2022 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001387561533/0DECK CASING 100C (GREY)£669.11 Add to
0021134-5595-01BLIND RIVET NUT£8.32 Add to
003387869545/0RH SIDE PROTECTION ASSY CD100QF GREY£75.23 Add to
004387869547/0LH SIDE PROTECTION ASSY CD100QF GREY£75.23 Add to
005112154220/0SELF-LOCK FLANGED NUT M8£3.03 Add to
006112800815/0SCREW TE FL M8 x 16£2.06 Add to
007112692050/0HEX-HEAD SCREW£1.91 Add to
008387001013/0LINKAGE ASSEMBLY R/H£129.74 Add to
009387001015/0LINKAGE ASSEMBLY L/H£129.74 Add to
0101137-0151-01SHAFT£3.00 Add to
011112155000/0LOW SELF-LOCKING NUT M8£2.06 Add to
012387869281/0FRONT GUARD TUBE (GREY)£345.73 Add to
013137038009/0WHEEL BUSH£6.09 Add to
014112379511/0STRAIGHT GREASE NIPPLE M6 x 1£2.06 Add to
015112794970/0HEX-HEAD SCREW M10 x 90£3.15 Add to
0169699-0030-02WASHER (10 X 26 X 2)£2.14 Add to
0171134-5677-01SPACER£18.74 Add to
0181134-5884-01PIVOT WHEEL ASSEMBLY£58.87 Add to
019112156602/0LOW SELF-LOCKING NUT M10£1.79 Add to
020187000218/0UNLOCK COMMAND CABLE 100QF£17.86 Add to
021112400031/0PIN D=5£2.06 Add to
022337315011/0L/H DECK UNLOCK LEVER 110/125 QF£5.87 Add to
023337315010/0R/H DECK UNLOCK LEVER 110/125 QF£5.87 Add to
024112604897/0STARLOCK WASHER D=5£2.06 Add to
0259893-0616-16SCREW M6 x 16£2.47 Add to
026337785055/0DECK LEVER SUPPORT 110/125 QF£3.41 Add to
0271134-2629-01LIFT LINK£15.69 Add to
028387432003/0110/125 DECK LIFT SPRING£47.97 Add to
0291134-6368-02CHAIN [7 LINKS]£24.95 Add to
0301134-5528-01SNAP HOOK£4.52 Add to
033387106295/0GAP L/H LIFTING DECK ARM 100C QF£110.66 Add to
034387106293/0R/H LIFTING DECK ARM 100C QF£117.47 Add to
035112691600/0HEX-HEAD SCREW M8x70 UNI 5737 ACC.8.8£1.91 Add to
036112523060/0WASHER M8 8.4 X 24 X 2£2.06 Add to
037137038011/0BUSH£3.72 Add to
038137510334/0FULCRUM PIN 95/100/105QF£10.36 Add to
039112800815/0SCREW TE FL M8 x 16£2.06 Add to
040112523060/0WASHER M8 8.4 X 24 X 2£2.06 Add to
041337022757/0RATCHET PAWL 95/100/105QF£17.45 Add to
042137430113/0TRACTION SPRING£5.87 Add to
044112523060/0WASHER M8 8.4 X 24 X 2£2.06 Add to
045112155000/0LOW SELF-LOCKING NUT M8£2.06 Add to
046137510306/0SPRING GUIDE PIN£8.19 Add to
047137430104/0DECK SPRING£4.52 Add to
048387773571/1R/H BRACKET£111.46 Add to
049387773573/1GAP L/H ROT. BRACKET CD95/100/105QF ASSY£99.76 Add to
050337394207/0QF FM-CD ROTATION RELEASE KNOB£6.27 Add to
051112523040/0WASHER M6 6.6 x 18 x 1.6£2.06 Add to
052112582100/0LOCK WASHER M6£2.06 Add to
053112727807/0SCREW TCB TORX M6 x 16£2.81 Add to
054337600049/1R/H HOOK DECK COVER£12.03 Add to
055337600050/1L/H HOOK DECK COVER£10.77 Add to
056112691115/0HEX-HEAD SCREW M8 x 40£2.06 Add to
057387773569/0WZ PISTON GUIDE EL.LIFT.BRACK.CD100 ASSY£35.71 Add to
058137160015/0SPACER EL. LIFTER CD100QF£6.95 Add to
059112154220/0SELF-LOCK FLANGED NUT M8£3.03 Add to
0609646-0105-22RIVET£3.41 Add to
061112604899/0STARLOCK WASHER RPCO 308 D=8£2.06 Add to
062118001004/2ELECTRIC LIFTER CD 95-100-105£401.85 Add to
063387149301/0ACTUATOR CABLE L=490£23.72 Add to
0649646-0098-22RIVET 8 x 32£2.87 Add to
0651137-0160-01PUSH ROD R/H£12.96 Add to
066387000317/0WZ L/H HEIGHT ADJ ROD ASSY CD100QF£16.22 Add to
067112604903/0STARLOCK WASHER D=10£2.06 Add to
068387000161/0REAR DECK AXLE (GREY)£83.51 Add to
0699646-0098-22RIVET 8 x 32£2.87 Add to
070112604899/0STARLOCK WASHER RPCO 308 D=8£2.06 Add to
0711134-6198-01STUD£20.66 Add to
0729598-2001-02SPRING PIN£5.19 Add to
073112521390/0WASHER M16 17 x 30 x 3£1.91 Add to
0741134-6282-02ROLLER ASSEMBLY R/H£57.52 Add to
0751134-6282-01ROLLER ASSEMBLY L/H£57.52 Add to
076112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
0779897-0813-02SCREW M8 x 130£5.06 Add to
0781134-9126-01SUPPORT ROLLERS [2 PCS]£43.89 Add to
0791134-4318-01SPACER TUBE£10.50 Add to
081112800815/0SCREW TE FL M8 x 16£2.06 Add to
0821134-4185-01FLANGE WASHER£6.71 Add to
0821134-4185-01FLANGE WASHER£6.71 Add to
0831134-6281-03RUBBER GUARD£22.22 Add to
084112154220/0SELF-LOCK FLANGED NUT M8£3.03 Add to
085337546712/0CABLE CLAMP PLATE CD100QF£4.10 Add to
