Transmission Group

Transmission Group assembly details for Stiga PARK PRO 740 IOX 2015 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	118475000/0	HYDRAULIC PUMP KPL-13ALP	£2,031.83	Add to
002	1139-1514-01	HOUSING	£803.19	Add to
005	1139-1527-01	REPAIR KIT	£1,008.67	Add to
006	1139-1021-01	CIRCLIP	£2.06	Add to
012	1139-1396-01	SEAL	£23.31	Add to
013	118870050/0	METAL THRUST	£15.28	Add to
014	118870051/0	PLATE	£244.45	Add to
015	118870052/0	WASHER	£49.76	Add to
016	118870053/0	BEARING	£49.76	Add to
017	118870054/0	WASHER	£82.33	Add to
018	118870055/0	CYLINDER BLOCK KIT	£386.11	Add to
019	1139-1515-01	CASE GASKET	£16.19	Add to
020	118870056/0	CENTRAL CASE ASSEMBLY	£1,259.62	Add to
021	1139-1513-01	VALVE PLATE	£107.27	Add to
022	1139-1166-01	PIN	£4.94	Add to
023	1139-1368-01	CHECK VALVE F	£38.16	Add to
035	1139-1114-01	O RING	£4.80	Add to
050	118870057/0	NEUTRAL RETURN ASSEMBLY	£425.45	Add to
051	1139-1127-01	NUT	£3.40	Add to
052	1139-1102-01	WASHER	£5.75	Add to
056	118870058/0	SPRING	£43.30	Add to
058	1139-1392-01	RING	£2.47	Add to
060	1139-1127-01	NUT	£3.40	Add to
062	1139-1372-01	BY-PASS LEVER	£61.17	Add to
065	1139-1115-01	O RING	£1.79	Add to
067	1139-1387-01	RING BACK-UP RING	£7.34	Add to
068	1139-1112-01	O RING	£4.01	Add to
