Body

Body assembly details for Stiga PARK 340 X 2017 (2F6130511/S16) 2017 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	1134-6025-01	ENGINE HOOD [YELLOW]	£346.76	Add to
002	9893-0616-16	SCREW M6 x 16	£2.47	Add to
003	1134-9028-01	RUBBER STRAP (3 PCS)	£26.46	Add to
004	9632-0513-00	POP RIVET 3.2 x 20	£2.06	Add to
005	9699-0120-02	WASHER 3.2 x 14 x 1.5	£2.32	Add to
006	337110334/0	TOP ENGINE COVER [GREY]	£77.95	Add to
007	337110336/0	LEFT BUMPER END	£15.00	Add to
008	337110335/0	RIGHT BUMPER END	£14.32	Add to
009	1134-6310-01	CLIP	£2.32	Add to
010	337580302/0	PLATE [YELLOW]	£7.63	Add to
019	1134-6241-01	HOOD SUPPORT	£42.53	Add to
026	112735594/0	HEX-HEAD SCREW M6 x 30	£2.06	Add to
031	337491255/0	LEFT MUDGUARD [GREY]	£114.74	Add to
032	337491254/0	RIGHT MUDGUARD [GREY]	£114.74	Add to
033	9893-0616-16	SCREW M6 x 16	£2.47	Add to
034	1134-4176-01	CLIP	£5.19	Add to
035	1137-0088-01	SUPPORT PLATE	£2.74	Add to
036	9945-0816-16	SCREW M8 X 16	£2.54	Add to
037	112523060/0	WASHER M8 8.4 X 24 X 2	£2.06	Add to
038	337502509/0	LEFT FRONT BUMPER [GREY]	£53.42	Add to
039	337502508/0	RIGHT FRONT BUMPER [GREY]	£50.94	Add to
040	9893-0616-16	SCREW M6 x 16	£2.47	Add to
041	1134-5305-01	FRONT BUMPER [YELLOW]	£84.77	Add to
042	9893-0616-16	SCREW M6 x 16	£2.47	Add to
043	1134-5320-05	FRONT UPPER COVER [YELLOW]	£41.10	Add to
043A	337110321/0	UPPER FRONT COVER [YELLOW]	£58.57	Add to
044	9946-0525-16	SCREW M5 x 25	£2.47	Add to
045	337110331/0	LEFT MOULDING [GREY]	£57.15	Add to
046	337110332/0	RIGHT MOULDING [GREY]	£54.79	Add to
047	9893-0616-16	SCREW M6 x 16	£2.47	Add to
048	112523040/0	WASHER M6 6.6 x 18 x 1.6	£2.06	Add to
049	112154510/0	LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S	£2.06	Add to
050	112815200/0	SCREW TTDQ M6X16	£2.06	Add to
