Sweeper (2)

Sweeper (2) assembly details for Stiga FRONT SWEEPER 299900500-1 2016 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
007118890050/0Guard, Drive Shaft Guard, Drive ShaftN/A POA
008118890051/0Cover CoverN/A POA
018118890055/0GUARD£39.69 Add to
0209739-1031-22NUT M10£2.32 Add to
0211319-2263-01WORM GEAR (7:1)£588.19 Add to
0221319-2261-01PULLEY£90.57 Add to
0271319-1539-01BEARING£84.77 Add to
0291319-2281-01Screw£6.25 Add to
0301319-2253-01BEARING£9.82 Add to
032118890057/0Collar, lock Collar, lockN/A POA
0339915-0808-15Screw£4.01 Add to
034118890058/0SEAL RING£14.58 Add to
035118890059/0Plate, distanceN/A POA
036118890043/0Spring SpringN/A POA
037118890060/0Collar CollarN/A POA
0441319-2262-01Clamp£7.31 Add to
048118890038/0Grip GripN/A POA
050118890044/0SupportN/A POA
053112521350/0WASHER M8 8.4 x 16 x 1.6£2.06 Add to
0579699-0062-02WASHER BRB 8,4X22X1,5£2.06 Add to
058112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
060112793102/0SCREW TE M8x20 UNI 5739 ACC.8.8£2.06 Add to
063112521370/0WASHER M12 13 24 x 2.5£2.06 Add to
0649747-1231-02NUT£2.06 Add to
0669997-0870-16SCREW M6S M8 x 70£2.47 Add to
067112792610/0HEX-HEAD SCREW M8 x 16£2.02 Add to
069118890040/0ANGLE CONTROL ROD£125.61 Add to
070118890041/0Collar, cone Collar, coneN/A POA
071118890037/0ADJUSTING KNOB£5.29 Add to
072118890056/0BRACKET£120.90 Add to
073112521360/0WASHER M10 10.5 x 20 x 2£2.06 Add to
0749997-1030-16SCREW M6S M10 x 30£3.00 Add to
075112790780/0HEX HEAD SCREW M6X12£3.64 Add to
