Lawn rake (2)

Lawn rake (2) assembly details for Stiga LAWN RAKE Electric - Park 2+4WD 13-3902-11 2016 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
012	1319-1854-01	UNIVERSAL JOINT	£274.35	Add to
014	1319-1856-01	ANGLE GEARBOX	£393.97	Add to
026	13-1985-11	Rotor Shaft	£343.50	Add to
027	1319-1772-01	TINE KIT-104 Pieces (FLAIL MOWER)	£599.87	Add to
027	1319-1721-01	TINE-FLAIL MOWER	£5.87	Add to
028	1319-1722-01	AXLE ROD	£163.80	Add to
029	1319-1628-01	BEARING	£89.43	Add to
030	1319-1766-01	GUARD PLATE	£66.29	Add to
031	1319-1767-01	GUARD	£64.32	Add to
037	1319-1862-01	DRIVE SHAFT	£47.97	Add to
042	1134-9103-01	DECK DRIVE BELT [KEVLAR] - 4WD	£54.79	Add to
042	1134-9069-01	DECK DRIVE BELT	£32.99	Add to
044	1319-1732-01	COLLAR	£84.70	Add to
046	112293201/0	HEXAGON NUT M8 WITH EXAGONAL FLANGE	£2.06	Add to
051	112793301/0	HEX-HEAD SCREW M8 x 25	£2.06	Add to
055	112156602/0	LOW SELF-LOCKING NUT M10	£1.79	Add to
060	1319-1879-01	WASHER	£18.27	Add to
061	112521360/0	WASHER M10 10.5 x 20 x 2	£2.06	Add to
070	1319-1883-01	SCREW	£3.83	Add to
071	1319-1525-01	KEY	£23.72	Add to
079	1319-1881-01	SPRING PIN	£1.58	Add to
081	1319-1701-01	COLLAR	£4.99	Add to
084	1319-1880-01	SET SCREW	£1.83	Add to
092	1319-1860-01	DUST CAP	£7.15	Add to
093	1319-1885-01	Washer	£4.01	Add to
094	1319-1855-01	BELT PULLEY	£92.95	Add to
095	1319-1864-01	SHAFT GUARD	£25.13	Add to
097	1319-1884-01	KEY	£10.77	Add to
099	9997-1012-02	SCREW M6S M10 x 120	£6.63	Add to
101	1319-1882-01	Screw L = 130 mm	£4.01	Add to
107	1319-1903-01	KEY	£8.87	Add to
