Rotary brush (2)

Rotary brush (2) assembly details for Stiga SWEEPER 2 and 4WD - Park 13-0977-11 2016 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0039500-9982-00B&S 91084 Oil Plug£12.23 Add to
006112800815/0SCREW TE FL M8 x 16£2.06 Add to
0089997-0635-12ScrewN/A POA
0121134-2584-01SPROCKET£255.84 Add to
0139907-1020-19SCREW£2.61 Add to
0149695-0006-00Washer£4.01 Add to
0159591-0020-00Pin£4.01 Add to
0169549-0045-00BALL BEARING£63.64 Add to
0179404-0074-00SEAL RING£26.18 Add to
0209997-0670-12Screw£4.01 Add to
0221134-2587-01SPROCKET£84.77 Add to
0241319-1844-01GEAR WHEEL KIT (PAIR)£268.07 Add to
0269650-0017-04CIRCLIP£3.64 Add to
0281134-2585-01OUTPUT SHAFT 2011£222.34 Add to
0309549-0017-00BALL BEARING£12.14 Add to
0319589-0013-00CHAIN 78£101.13 Add to
0341111-1706-01CLAMP FRONT£8.28 Add to
035112292102/0FLANGED HEXAGONAL NUT M6£2.06 Add to
039120001215/0BEARING 6203 2RS C3£32.57 Add to
047112793102/0SCREW TE M8x20 UNI 5739 ACC.8.8£2.06 Add to
0501134-2588-01SHAFT£46.61 Add to
0519600-0148-00KEY£3.15 Add to
0539695-0005-00Washer£4.01 Add to
0541134-2589-01CHAIN TENSIONER£41.59 Add to
0641134-2590-01COMP.SPRING£17.83 Add to
0669943-0510-16ScrewN/A POA
0679651-0040-04CIRCLIP£2.74 Add to
0691319-1846-01PULLEY£80.68 Add to
0709600-0145-00Platt Key£4.01 Add to
0711134-4176-01CLIP£5.19 Add to
0731134-9041-01DRIVE BELT£46.61 Add to
0731134-9093-01Drive Belt = 9585-0144-01N/A POA
0741134-2796-02BOLT (355 MM)£39.22 Add to
0781319-1825-01BRUSH SHAFT£211.40 Add to
0791319-2333-01FLANGE£23.39 Add to
0859404-0073-00SEAL RING£32.99 Add to
0869591-0031-00PIN£5.21 Add to
0871134-3880-01BRUSH£15.13 Add to
0881134-3884-01BRUSH£16.62 Add to
1009997-1035-16SCREW M6S M10 x 35£3.28 Add to
1021319-1901-01SHAFT-LOWER£51.28 Add to
1031319-1952-01GEARBOX ASSEMBLY£842.54 Add to
