Blade

Blade assembly details for Stiga TURBO POWER 50 S H 295506038 2017 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001122465608/3BLADE BOSS D=25mm£11.34 Add to
002181004366/2MULCHING BLADE 48cm£16.36 Add to
003122160400/0SPRING WASHER 50 x 2 x 10.2£2.18 Add to
004112523080/0WASHER M10 11 x 30 x 2.5£2.06 Add to
005112735698/0HEX-HEAD SCREW 3/8" x 2"£2.02 Add to
006112139150/0WOODRUFF KEY D=25mm£2.14 Add to
007112691900/0HEX-HEAD SCREW£1.91 Add to
008112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
