Cylinder Barrel

Cylinder Barrel assembly details for Stiga Estate 3384 H (2T2100381/14) 2018 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	118551713/0	PAN ASSY., OIL	£606.68	Add to
002	118551720/0	PACKING, OIL PAN	£19.50	Add to
003	118551721/0	BARREL ASSY., CYLINDER	£1,860.35	Add to
004	118551747/0	TUBE, BREATHER	£16.22	Add to
005	118551753/0	CAP, BREATHER CHAMBER	£15.13	Add to
006	118551754/0	VALVE, BREATHER	£7.10	Add to
007	118551756/0	PACKING, BREATHER CAP	£3.69	Add to
010	118551885/0	COVER, OIL PUMP	£5.87	Add to
011	118551886/0	O-RING, PUMP COVER	£5.19	Add to
012	118551891/0	ROTOR COMP., INNER	£37.08	Add to
013	118551892/0	ROTOR, OIL PUMP OUTER	£30.26	Add to
014	118551893/0	PLATE, OIL FILTER	£7.78	Add to
022	118551896/0	SCREEN, OIL FILTER	£28.90	Add to
023	118551907/0	CAP ASSY., OIL FILLER	£24.95	Add to
025	118551909/0	EXTENSION COMP., OIL FILLER	£37.08	Add to
026	118551969/0	GOVERNOR ASSY.	£49.34	Add to
027	118551972/0	SLIDER, GOVERNOR	£4.64	Add to
028	118551979/0	SHAFT, GOVERNOR ARM	£17.04	Add to
037	118552244/0	GOVERNOR HOLDER CLIP	£1.74	Add to
039	118552248/0	BEARING, RADIAL BALL, 6202	£26.18	Add to
040	118552250/0	OIL SEAL, 35X52X8 (NOK)	£21.40	Add to
047	118552272/0	BOLT, DRAIN PLUG, 20MM	£7.63	Add to
048	118552273/0	PLAIN WASHER 6MM	£1.74	Add to
050	118552274/0	WASHER, DRAIN PLUG, 20MM	£2.87	Add to
057	118552278/0	BEARING, RADIAL BALL, 6207	£49.34	Add to
058	118551902/0	CAP ASSY., DRAIN	£12.82	Add to
060	118551915/0	ADAPTER, OIL DRAIN EXTENSION	£32.99	Add to
