Technical Specs
General info
EAN/UPC 8008984853508
SKU 240421602/ST1
Level Experience
Series Series 5
Power
Power 1.9 kW
Power source Petrol 2-stroke
Displacement 42.4 cm³
Engine rotation speed 12000 rpm
Maximum engine speed 12000 rpm
Idling speed (+/- 100) 3100 rpm
Starter Recoil
Primer Yes
Choke Manual
Fuel tank capacity 0.49 L
Carburettor type Butterfly valve
Ignition coil type Digital
Air filter type Nylon net
Cutting system
Bar type Sprocket nose
Bar length 40 cm
Bar length (inches) 16 in
Chain type .325" .050" (95VPX066X)
Chain speed 23.1 m/s
Chain brake Manual and inertial
Chain oil tank capacity 0.26 L
Chain oil pump Automatic adjustable
Chain tensioning system Side screw tensioning
Equipment
Handle type Rear handle
Vibe Control System (VCS) Yes
Soft grip handle Yes
Tools kit
Included tools kit Screwdriver, chain round file, spark plug key
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A) 114
Measured sound power level dB(A) 110.3
Measured sound pressure level at operator ear dB(A) 98.7
Vibration level front handle (m/s2) 5.93
Vibration level rear handle (m/s2) 5.4
Overall dimensions
Pack weight 8.33 kg
Weight 7.62 kg
Product weight without bar and chain 5.87 kg
Product length 775 mm
Product width 283 mm
Product height 315 mm
