Power Engine: Type Water-cooled, 4-cycle, diesel, indirect injection
Displacement 1123cc
No of cylinders 3
Power 14.6kW (20 hp) at 2600rpm
Fuel capacity 21ltr (4.6 gal)
Transmission Type HST (Hydrostatic transmission)
Rear axle Chain drive to each wheel
Brakes Type Dry, internal expanding shoe
No. of brakes 1 before diff (garden version) 2 after diff (homologated road legal version)
Tyres Front 16 x 8.50-8
Rear 23 x 10.50-12
Dimensions Length 2140mm (84.3”)
Width 1110mm (43.3”)
Overall height 2140mm (84”) or 1830mm (72”) with ROPS folded
Weight 515kg (1135lbs) Garden model
Mower Deck SCMA 54 No of blades: 2 Rear Discharge
Cutting width 1220mm (48”)
Cutting height 25mm (1.0”) - 115mm (4.5”) by pin or 25mm (1.0”) - 90mm (3.5”) by dial
Adjustments 7 stages by pin replacement and stepless dial
Weight Deck 97kg (214lbs), link 8kg (18lbs)
Weight 210kg (463 lbs)
