Power Engine: Type Vertical, Water-cooled, 4-cycle, diesel
Displacement 1123cc
No of cylinders 3
Power 16.3kW (22.2hp) at 2600rpm
Fuel capacity 21ltr (4.6 gal)
Transmission Type HST (Hydrostatic transmission)
Brakes Type Dry internal
No. of brakes 1 before diff (homologated version: 2 after diff)
Tyres Front 18 x 8.50-8
Rear 26 x 10.50-12
Dimensions Length 2110 mm (83.1”)
Width 1170 mm (46.1”)
Overall height 1320 mm (52”)
Weight 530kg (1168 lbs)
Mower Deck SCMA 54 No of blades: 2
Centre rear discharge rotary, synchronised blades
Cutting width 1.372m (54”) Cutting height 25mm (1.0”) - 115mm (4.5”)
Adjustments 7 stages by pin replacement and stepless dial
Weight Deck 96kg (212 lbs), link 9kg (20 lbs)
Rear Deflector
